Product
|
|
|
|
|
Consumer Routers
|
H101C
|
A500Q
|
A500M
|
|
Cellular
|
|
Standard
|
3GPP Rel-15 NSA/SA
|
3GPP Release 16 NSA/SA
|
3GPP Release 16 NSA/SA
|
|
Region
|
For EMEA and related countries
|
EMEA/Oceania/Brazil/North America
|
EMEA/Oceania/Brazil/North America
|
|
NR bands
|
NSA: n41/n78/n79, SA: n1/n28/n41/n77/n78/n79
|
5G NR:
3GPP Release 16 NSA/SA
operation, Sub-6 GHz
5G NSA & SA:
n1/n3/n5/n7/n8/n20/n28/n38/
n40/n41/n75/n76/n77/n78
|
5G NR:
3GPP Release 16 NSA/SA
operation, Sub-6 GHz
5G NSA & SA:
n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n75/n76/n77/n78
|
|
LTE category
|
DL Cat 12/ UL Cat 13
|
DL 4 × 4 MIMO on:
B1/B3/B7/B38/B40/B41/
B42/B43
|
DL 4 × 4 MIMO on:B1/B3/B7/B38/B40/B41/B42
|
|
MIMO
|
DL 4 × 4 MIMO on: n1/n41/n77/n78/n79
|
5G DL 4×4 MIMO on:
n1/n3/n7/n38/n40/n41/
n75/n76/n77/n78
LTE DL 4 × 4 MIMO on:
B1/B3/B7/B38/B40/B41/
B42/B43
|
5G DL 4×4 MIMO on:n1/n3/n7/n38/n40/n41/n75/n76/n77/n78
LTE DL 4 × 4 MIMO on:B1/B3/B7/B38/B40/B41/B42
|
|
LTE-TDD
|
B34/B38/B39/B40/B41
|
B38/B40/B41/B42/B43
|
B38/B40/B41/B42/B43
|
|
LTE-FDD
|
B1/B3/B5/B8
|
B1/B3/B5/B7/B8/B20/B28/B32
|
B1/B3/B5/B7/B8/B20/B28/B32
|
|
Built-in antenna
|
4G/5G antenna × 4
|
4G/5G antenna*4, Wi-Fi antenna(MU MIMO)*6
|
4G/5G antenna*8, Wi-Fi antenna(MU MIMO)*4
|
|
WCDMA
|
B1/B2/B5/B8
|
|
B1/B5/B8
|
|
Max data rates
|
5G NSA Sub-6: 2.2 Gbp(DL)/575 Mbps (UL), 5G SA Sub-6: 2Gbps (DL)/ 1Gbps(UL), LTE: 400 Mbps (DL)/150 Mbps (UL)
|
5G NSA Sub-6: 3.2Gbps (DL)/600 Mbps (UL)
5G SA Sub-6: 2.4Gbps (DL)/900 Mbps (UL)
LTE: 1.6 Gbps (DL)/200 Mbps (UL)
WCDMA: 42 Mbps (DL)/5.76 Mbps (UL)
|
5G NSA Sub-6:3.74Gbps (DL)/1.46Gbps (UL)
5G SA Sub-6: 4.67Gbps (DL)/2.5Gbps (UL)
LTE: 1.4Gbps (DL)/211Mbps (UL)
WCDMA: 42 Mbps (DL)/5.76 Mbps (UL)
|
|
Wireless
|
|
Standard
|
Wi-Fi 5, 802.11 a/b/g/n/ac
|
Wi-Fi 6 802.11 a/b/g/n/ac/ax
|
Wi-Fi 6 802.11 a/b/g/n/ac/ax
|
|
2.4 GHz
|
2 × 2 MIMO, 300Mbps
|
2*2 MIMO, 576Mbps
|
4*4 MIMO, 1200Mbps
|
|
5 GHz
|
2 × 2 MIMO, 866Mbps
|
802.11 a/b/g/n/ac/ax, 4*4 MIMO, 4804Mbps
|
4*4 MIMO, 2400Mbps
|
|
Max User
|
64
|
128
|
64
|
|
Built-in antenna
|
Wi-Fi antenna × 4 (MU MIMO)
|
4G/5G antenna*4, Wi-Fi antenna(MU MIMO)*6
|
4G/5G antenna*8, Wi-Fi antenna(MU MIMO)*4
|
|
Interface
|
|
LED
|
Power, Wi-Fi, 4G, 5G
|
Power, Wi-Fi, 4G, 5G
|
Power, Wi-Fi, 4G, 5G
|
|
Button
|
RESET, Power, WPS
|
RESET, Power, WPS
|
RESET, Power, WPS
|
|
SIM
|
Micro SIM
|
4FF SIM (Nano SIM)
|
4FF SIM(Nano SIM)
|
|
Ethernet
|
1 GigE LAN, 1 GigE WAN/LAN
|
1*10/100/1000Mbps LAN, 1*10/100/1000/2500Mbps LAN/WAN
|
1*10/100/1000Mbps LAN, 1*10/100/1000Mbps LAN/WAN
|
|
Power Supply
|
|
Power input
|
Power adaptor, DC socket
|
Power adaptor, DC socket
|
Power adaptor, DC socket
|
|
Voltage
|
12V/1.5A
|
+12VDC/3A
|
+12VDC/2A
|
|
Others
|
|
Weight
|
Approx. 450g
|
About 800g
|
About 610g (without power adapter)
|
|
Size
|
175 × 175 × 48.5mm
|
100mm* 100mm* 205mm
|
94.3mm* 107.1mm* 186.5mm
|
|
Operating temperature
|
-10～+45°C
|
-10ºC+45ºC
|
-10ºC+55ºC
|
|
Storage temperature
|
-40～+70°C
|
-30ºC+75ºC
|
-20ºC+70ºC
|
|
Relative humidity
|
≤ 95%(no condensing)
|
≤95%
|
≤95%
|
