| Hardware |
| CPU | Dual-core, 1.35 GHz, ARM Cortex A53 |
| RAM | 256MB |
| FLASH | 32MB |
| Cellular Interface |
| Modem | 1 x 5G NR SA/NSA |
| Number of antennas | 4 |
| Connector | Built-in antennas |
| SIM | 2 x Mini SIM (2FF)(eSIM Optional) |
| Ethernet Interface |
| Number of ports | 3×LAN 10/100/1000 Mbps+1×WAN/LAN 10/100/1000 Mbps, Gigabit Ethernet |
| Configuration | 1x LAN + 1 x WAN/LAN |
| PoE output | POE+(802.3af/at) 30W output × 1, input×1 |
| Wireless interface |
| Standards | (Optional)802.11b/g/n/ac/ax, AP or station mode |
| Frequency bands | 2.4 GHz & 5GHz |
| Speed | 2402Mbps on 5GHz, 576Mbps on
2.4GHz |
| Security | WEP, WPA, WPA2 |
| Encryption | 64/128 AES, TKIP |
| Antennas | 3 |
| Connector | Built-in antennas |
| Seiral interface |
| SD card | Built-in TF card slot |
| Software |
| Auto fail-over | Between:
Cellular and WAN
Cellular and Wi-Fi (station mode)
WAN and Wi-Fi (station mode) |
| Network protocols | PPP,PPPoE,TCP,UDP,IPv4,IPv6,SSL,DHCP,ICMP, NAT,HTTP,HTTPs, DNS, ARP,NTP,Telnet, SSH, DDNS, etc. |
| Network | APN, VLAN, QoS |
| Routing | Static Routing, Policy routing, RIP, OSPF and BGP, etc |
| Firewall | NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List |
| VPN | PPTP/L2TP/GRE/IPSec/OpenVPN |
| Attack Prevention |
| Ipsec Encryption | DES, 3DES, AES128, AES192, AES256 |
| OpenVPN Encryption | BF-CBC, DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC,
AES-192-CBC, AES-256-CBC, SEED-CBC |
| Remote Management | HTTP, Telnet, SSH, SMS
SNMP V1/V2/V3, SNMP TRAP
Hongdian Sandora Platform, SDLAN |
| Power Supply and Consumption |
| Power Connector | DC socket or LAN POE-in |
| Voltage input | +9V~+48V DC |
| Power consumption | Idle: 450mA@12V DC
Data transceiving: 2.2A@12V DC |
| Others |
| Reset button | Yes |
| LED indicators | 4 indicators for WiFi, SIG, NET, SYS |
| Hardware watchdog | Yes |
| Physical Characteristics |
| Ingress protection | IP66 |
| Housing & Weight | Plastic, 800g |
| Dimension | 250×145×67.5(mm) |
| Installations | Pole mounting, wall mounting |
| Operating temperature | -30 ~ +50℃ |
| Storage temperature | -40 ~ +80 °C |
| Relative humidity | 5 ~ 95% RH |
| EMC | |
| ESD | EN61000-4-2, level3 |
| RS | EN 61000-4-3, level3 |
| EFT | EN 61000-4-4, level3 |
| CS | EN 61000-4-6, level3 |
Certifications
(*In progress) | CE*, FCC* |
